Fadal VH65 4th Axis Upgrade Kit, VMC4020 DC Machine, 1400-5 CPU
Part number: WIR-0077-DC5
In stock
SKU
WIR-0077-DC5
$3,200.00
Out of Stock
This is a 4th Axis Rotary kit for a DC Machine with AMP-0015 or AMP-0021 large style amplifiers.
It is for a 1400-4 CPU System that has 1010-5 or 1010-6 Axis Cards in it.
It does not include the prewire because some machine already came pre wired.
If you need to order the prewire then order WIR-0075 here.
| Warranty | New One Year Warranty Reman 6 Month Warranty |
|---|---|
| Repair Price | No |
This kit includes:
- PCB-0217, 1010-6, A Axis
- ELE-0030 ABNOLIM Eproms
- AMP-0021-ITS, DC AMP
- WIR-0578 Inhibitor Assembly
- VLV-0053 Single Port Valve & Manifold
- WIR-0131 Dummy Plug
- ELE-0070 Sold State Relay
- ELE-0143 Overload Relay w/Heater
- VLV-KIT-1 Fittings & Hose.
Use PCB-0035, 1010-4 instead of 1010-5,6 on 1400-4 Systems.
Use ELE-0021 ABNOLIM EPROMS for 1400-4 Systems.
Click Here to download the Maintenance Manual on Rotary Tables.
New One Year Warranty Reman 6 Month Warranty
